- PT-2090 table type constant temperature and humidity test machine
Temperature Humidity & Tester Programmable
Design standards: GB/T2423//5170/10586, C60068 ASTM, D4714 CNS3625/12565/12566, JIS
Table type constant temperature and humidity test machine uses: This product can be simulated high temperature and high humidity, high temperature and low humidity, low temperature and low humidity and different test environment. It is suitable for simulating the aging resistance of various materials in a variety of specific environments, and can also be used as a sample pretreatment for other physical testing. Technical specification:
Product model
PT-2090
Inner box size mm
450×300×400（W×D×H）
Box size mm
965×722×816（W×D×H）
Internal volume (L)
54
Performance
Temperature range
-10、-20、-40～1000C（Maximum reachable 1500C)
Temperature control precision
±0.3℃
Temperature distribution precision
±0.5℃
Humidity range
20％～98％(See range table)
Humidity control precision
±2.5％RH
Humidity distribution precision
±3.0％RH
Circulatory system
Fan forced circulation mode
Heating system
SUS #304,Stainless steel heater
Humidification system
Surface evaporation method, transparent structure
Cooling system
Fan cooling mode, high efficiency fully enclosed compressor
Desiccant system
Freezing latent heat desiccant method
Water supply
Water supply mode
Pump lift
Storage tank
Built in drawer type water tank, easy to add water
Backwater system
Automatic recycling, the problem of long water, and to ensure that the water quality is clean
Texture of material
Inside the box
SUS#304 heat resistant stainless steel
Outside the box
SUS#304 stainless steel with a matte fringe processing or senior paint (user specified)
Heat insulating layer
Imported new PU foam material
Safety device
Leakage, overload, over load, over temperature, over temperature, moisture, water shortage, and over - temperature protection
Standard equipment
A 2 group, vacuum observation window, indoor light, anti sweat demisting device
Power Supply
220V,5KW
